Rustler M170

M170
M170-Angle
Linhai_Lifestyle_Photos (3 of 3)
M170
M170-Angle
Linhai_Lifestyle_Photos (3 of 3)
Add To Compare
Share This
Contact Dealer

Specifications

Make
Linhai
Model
Rustler M170

Engine

Torque
10.5/6500 (Nm/r/min)
Engine Output
7.5/7500(kw/r/min)
Starter System
Electric starting
Horsepower
10.1 hp
Transmission/Final Drive
F-N-R
Carburetion Type
Carburetor
Engine Type
4-stroke, 1-Cylinder, Air-cooled
Engine displacement
149.6 cc
Bore x stroke
57.4 × 57.8 mm
Compression ratio
10.3:1

Suspension/Brakes

Front Suspension
Dual A arms independent suspension
Rear Suspension
Swing arm
Front Brake
Hydraulic Disc
Rear Brake
Hydraulic Disc
Front Tyre/s
AT24 x 8-12
Rear Tyre/s
AT24 x 11-10

Specifications

Branch
Quads

Overview

M170

STANDARD FEATURES:
  • MODEL: M170
  • SIZE: L x W x H 1905 x 1048 x 1150mm
  • WHEELBASE: 1180 mm
  • GROUND CLEARANCE: 140 mm
  • DRY WIEGHT: 188.5 KG
  • FUEL TANK CAPACITY: 8.35L
  • MAX SPEED: >55 km/h
  • DRIVE SYSTEM TYPE: Chain Drive
