Promax 320 4×4

Final300desert-1024x576
Linhai_300_Lifestyle_8
Linhai_300_Lifestyle_3
Linhai_300_Lifestyle_2
Final300desert-1024x576
Linhai_300_Lifestyle_8
Linhai_300_Lifestyle_3
Linhai_300_Lifestyle_2
Add To Compare
Share This
Contact Dealer

Specifications

Make
Linhai
Model
Promax 320 4x4

Engine

Torque
23/5500 (Nm/r/min)
Engine Output
16/6500-7000 (kw/r/min)
Starter System
Electric starting
Drive System Type
2WD/4WD
Horsepower
21.4 hp
Transmission/Final Drive
Automatic L/H/N/R
Carburetion Type
CARB/EFI
Engine Type
1-Cylinder, Water Cooling, Automatic
Engine displacement
275 cc
Bore x stroke
72.5×66.8 mm
Compression ratio
9.5:1

Dimensions / Weights

Front/Rear Rack
20 kg / 40 kg
Hitch Towing Rating
100kg
Overall Vehicle Size (L x W x H)
2120 x 1140 x 1270 mm
Payload Capacity
150 KG
Person Capacity
1
Wheelbase (mm)
1215 mm
Dry Weight (lbs/kg)
295 KG
Ground Clearance
183 mm

Suspension/Brakes

Front Suspension
McPherson independent suspension
Rear Suspension
Swing Arm / Solid Axle
Front Brake
Hydraulic Disc
Rear Brake
Hydraulic Disc
Front Tyre/s
AT24 x 8-12
Rear Tyre/s
AT24 x 11-10

Specifications

Branch
Quads
DOWNLOAD BROCHURE
  • Overview
  • Featured Options
  • Videos

Overview

PROMAX 320 4×4

STANDARD FEATURES:
  • MODEL: ATV320
  • SIZE: L x W x H 2120 x 1140 x 1270 mm
  • WHEELBASE: 1215 mm
  • GROUND CLEARANCE: 183 mm
  • DRY WEIGHT: 295 KG
  • FUEL TANK CAPACITY: 14L
  • MAX SPEED: >60 km/h
  • DRIVE SYSTEM TYPE: 2WD/4WD

Featured Options

The Linhai Promax 320 is a compact and agile utility ATV designed for off-road use. It is powered by a liquid-cooled 275cc single cylinder four-stroke engine, which delivers strong and smooth performance. The Promax 320 features a fully automatic CVT transmission with high and low range, which provides effortless and convenient operation. It has a selectable 2WD/4WD drive system with a front differential lock, allowing the rider to switch between modes for better traction and handling. The Promax 320 also features a sturdy cargo rack and a towing capacity of up to 100kg, making it a versatile and practical workhorse. Overall, the Linhai Promax 320 is a reliable and capable ATV that can handle a wide range of tasks and environments.
